3-15
Confidential
The harness colors may change due to circumstances.
The harness colors may change due to circumstances.
5 Head/carriage unit
6 ADF unit and document scanner unit
Hooks
Boss
Carriage PCB flat cables 1/2/3
(white)
(3_124_E)
Second side CIS flat cable
(white)
Cable guides
ADF motor harness
Scanner motor harness
First side CIS flat cable
(black)
Document detection
sensor harness
Document scanning position
sensor harness
(3_125_1_E)
