5-36
Confidential
For the LF resolution 300 adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key twice.
The "1. LF300" appears on the LCD.
(4) Press the 1 key.
The "LF300 NO. +0" appears on the LCD.
(5) On the pfadj2 pattern (see page 5-39), check the LF300 row of blocks. In the same way as
in step (4) of the adjustment of all paper feeding correction values, enter the number of the
block that is the least uneven print and then press the SET key.
Press the STOP key to return the machine to the initial stage of the maintenance mode.
For the PF roller alone adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key three times.
The "1. PF_ONLY" appears on the LCD.
(4) Press the 1 key.
The "PF_ONLY NO. +0" appears on the LCD.
(5) On the pfadj1 pattern (see page 5-38), check the PF0 row of blocks. In the same way as in
step (4) of the adjustment of all paper feeding correction values, enter the number of the
block that is the least uneven print and then press the SET key.
Press the STOP key to return the machine to the initial stage of the maintenance mode.
For corrugation feed adjustment
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the key four times.
The "1.COR_FEED(T2)" appears on the LCD.
(4) Press the 1 key.
The "CORFEED NO. +0" appears on the LCD.
To Next Page
