5-37
Confidential
(5) On the pfadj2 pattern (see page 5-39), check the CORF row of blocks. In the same way as
in step (4) of the adjustment of all paper feeding correction values, enter the number of the
block that is the least uneven print and then press the SET key.
Press the STOP key to return the machine to the initial stage of the maintenance mode.
For initialization of adjustment values
(1) Press the 5 and 8 keys in this order in the initial stage of the maintenance mode.
The "Select 58?" appears on the LCD.
(2) Press the Mono Start key.
The "1. ALL" appears on the LCD.
(3) Press the 8, 9, 5, and 4 keys in this order.
The machine initializes all paper feeding correction values.
The "CLEAR PF & EXIT" and "1. ALL" appear.
Press the STOP key to return the machine to the initial stage of the maintenance mode.
To Next Page
