Brother MFC-J5330DW Service Manual

5-4
Confidential
1.2 List of Maintenance-mode Functions
Shaded maintenance mode functions are available to end users.
* Exclusive to the end user-accessible maintenance mode.
Maintenance
Mode
Function
Reference Section
(Page)
01 EEPROM Parameter Initialization 1.3.1 (5-5)
02 Creating of Head Calibration Data and Writing it into Flash ROM 1.3.2 (5-6)
08 ADF Performance Test 1.3.3 (5-10)
09 Printout of Test Pattern 1.3.4 (5-11)
10 Worker Switch (WSW) Setting 1.3.5 (5-12)
11 Printout of Worker Switch (WSW) Data 1.3.5 (5-12)
12 Operational Check of LCD 1.3.6 (5-15)
13 Operational Check of Keys on Control Panel 1.3.7 (5-16)
28 Updating of Firmware Using a USB flash memory 1.3.8 (5-17)
32 Sensor Operational Check 1.3.9 (5-18)
37* Printout of Dial Log 1.3.10 (5-20)
45 PCL/PS function setting (MFC-J5930DW only) 1.3.11 (5-21)
46 Backup of Machine Information 1.3.12 (5-23)
53 Transfer of Received FAX Data and/or Equipment's Log 1.3.13 (5-25)
54 Fine Adjustment of Scanning Position 1.3.14 (5-27)
55 Acquisition of White/Black Level Data 1.3.15 (5-28)
57 Cartridge IC Communication Check 1.3.16 (5-29)
58 Updating of Paper Feeding Correction Values 1.3.17 (5-30)
59 Checking of CIS Travel and Setting of CIS Type 1.3.18 (5-35)
61 Printout of PRN/JPEG Files in USB Flash Memory 1.3.19 (5-36)
63 Move of the Head/Carriage Unit to the Adjustment Position 1.3.20 (5-37)
65
Adjustment of Software Correction for Inclination/Corrugation/
Ruled Lines
1.3.21 (5-38)
66 Adjustment of Margins in Borderless Printing 1.3.22 (5-39)
68
Updating of Head Property Data and Backup/Restoration of
Head Calibration Data
1.3.23 (5-41)
69 Traveling Speed Check of Head/Carriage Unit 1.3.24 (5-43)
74 Customizing Destinations 1.3.25 (5-43)
75 Move of the Head/Carriage Unit to the Flushing Position 1.3.26 (5-45)
76 Purge Operation 1.3.27 (5-46)
77 Print of the Maintenance Information 1.3.28 (5-49)
78 Adjustment of Touch Panel 1.3.29 (5-52)
80 Display of the Equipment's Log 1.3.30 (5-53)
82 Equipment Error Code Indication 1.3.31 (5-63)
87 Output of Transmission Log to the Telephone Line 1.3.32 (5-63)
88 Assurance Mode Switch Setting (AMS) 1.3.33 (5-64)
91 EEPROM Parameter Initialization 1.3.1 (5-5)
99 Exit from the Maintenance Mode

Brother MFC-J5330DW Specifications

General

Type	all in one, fax
Color	black
Touch Screen	yes
Display Size	2.7 inches
Tray Capacity	250
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Paper Size	letter, executive, envelope (com-10, dl envelope, monarch), a4, a5, a6 photo 4"x6", 3.5"x5", 5"x7", 5"x8", manual by-pass: 3.5" x 5" to 11" x 17"
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	glossy paper, inkjet paper (coated paper), plain paper, recycled paper
Two-Sided Printing	no
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 2400
Duplex Scan	yes
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3019bk/c/m/y inkvestment super high-yield cartridges, lc3017bk/c/m/y inkvestment super high-yield cartridges
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, google cloud print, mopria print service, usb, wi-fi, wi-fi direct
OS Compatibility	windows vista, 7, 8, 8.1, 10 home, 10 pro, 10 education, 10 enterprise, os x v10.9.5, os x v10.10.x, os x v10.11.x, hard disk space for drivers and apps
Mobile Devices Connection	yes

Weight and Dimensions

Depth	12 inches
Height	12 inches
Width	20.9 inches
Net Weight	36.8 pounds
