Confidential
2-57
4.2.6 Paper feeding at an angle
< User Check >
- Check that recording paper is loaded correctly in the paper tray.
- Adjust the paper guide to match the recording paper size.
- Check thickness of recording paper is within tolerance of each type.
- Check if too much paper is loaded in the paper tray.
- Clean the paper pull-in roller.
4.2.7 Recording paper jam
â–  Paper jam around the paper tray
< User Check >
- Check that recording paper is loaded correctly in the paper tray.
- Check that the paper tray is inserted all the way to the back end.
- Adjust the paper guide to match the recording paper size.
- Check that the paper smaller than the specified size is not loaded.
- Check thickness of recording paper is within tolerance of each type.
- Check that the number of recording paper loaded in the paper tray is within specified
volume.
- Check that the jam clear cover is securely closed.
- Clean the related rollers.
Step Cause Solution
1 Bank ASSY out of place Set the bank ASSY into place.
2
Paper feeding path parts out of place
Set the feeding path parts into place.
3 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Foreign materials in the
recording paper path
Remove foreign materials.
2 Bank ASSY out of place Set the bank ASSY into place.
3 Platen foam drift Set the platen foam into place.
4
Jam clear cover not mounted
in place
Set the jam clear cover into place.
5
CR guide rail not mounted in place
Set the CR guide rail into place.
6
Platen ASSY not mounted in place
Set the platen ASSY into place.
7
Platen spring not mounted in place
Set the platen spring into place.
8
Jam clear cover damaged, broken
Replace the jam clear cover.
9
Platen ASSY damaged, broken
Replace the platen ASSY.
10 Registration sensor defective Replace the registration sensor PCB ASSY.
11 Paper tray defective Replace the paper tray.
12 Main PCB defective Replace the main PCB.
