Brother MFC-J5330DW Service Manual

5-21
Confidential
1.3.11 PCL/PS function setting (Maintenance mode 45)
< Function >
This function is used to change the settings of the PCL/PS functions summarized in the
table below.
< Operating Procedure >
(1) Press the 4 and 5 keys in this order in the initial stage of the maintenance mode.
“JB-Can Time” is displayed on the LCD.
(2) Press the ▲ or ▼ key to select the function you want to set and press the SET key.
(3) For fixed parameters (On/Off, etc.), press the ▲ or ▼ key, or change the
parameter using the numeric keys. And press the SET key.
For parameters requiring numerical value entry, directly input a numeric value from
the ten-key pad and press the SET key.
(4) Press the X key to return the machine to the initial state of the maintenance mode.
■ Function setting
LCD
Detail description Set value Initial
JB-Can Time
Setting of the time until the host time-out at
the Job Cancel
0 to 225 (seconds) 4 (seconds)
Sleep Time
Setting of the time until enter the Sleep
Mode
0 to 99 (minutes) 5 (minutes)
Emulation Switching of the emulation Driver/Auto/PCL/PS Driver
Auto I/F Time Switching of the I/F open time 1 to 99 (seconds) 5 (seconds)
Media Type Switching of the paper type Plain/Glossy/Inkjet Plain
Paper Size Switching of the drawing size
Letter/Legal/A4/
Executive/B5/JISB5/A5/
B6/A6/Monarch/C5/
COM10/DL/DLL/
A4Long/Post Card/
Folio/Mexican Legal/
India Legal/A3/B4/16k
195x270
Letter or A4
Orientation Switching of the print direction Portrait/Landscape Portrait
Auto FF Switching of the auto form feed On/Off Off
Auto FF Time
Switching of the time-out period of the auto
form feed
1 to 99 (seconds) 5 (seconds)
Auto LF Switching of the auto LF On/Off Off
Auto CR Switching of the auto CR On/Off Off
Auto WRAP
Switching of the auto CRLF at the print width On/Off Off
Auto Skip
Switching of the Skip at the backend/tip of
the paper
On/Off On
Left Margin Switching of the margin at the left end 0 to 145 (columns) 0 (columns)
Right Margin Switching of the margin at the right end 10 to 155 (columns)
80
(columns)
Top Margin Switching of the margin at the upper end 0 to 2.00 (inches) 0.5 (inches)
Bottom Margin Switching of the margin at the bottom end 0 to 2.00 (inches) 0.5 (inches)
Lines Number of the text lines in the page 5 to 128 (lines) 60 (lines)
Error Print
Switching of the ErrorPrint of the
PostScript
On/Off On

Brother MFC-J5330DW Specifications

General

Type	all in one, fax
Color	black
Touch Screen	yes
Display Size	2.7 inches
Tray Capacity	250
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Paper Size	letter, executive, envelope (com-10, dl envelope, monarch), a4, a5, a6 photo 4"x6", 3.5"x5", 5"x7", 5"x8", manual by-pass: 3.5" x 5" to 11" x 17"
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	glossy paper, inkjet paper (coated paper), plain paper, recycled paper
Two-Sided Printing	no
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 2400
Duplex Scan	yes
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3019bk/c/m/y inkvestment super high-yield cartridges, lc3017bk/c/m/y inkvestment super high-yield cartridges
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, google cloud print, mopria print service, usb, wi-fi, wi-fi direct
OS Compatibility	windows vista, 7, 8, 8.1, 10 home, 10 pro, 10 education, 10 enterprise, os x v10.9.5, os x v10.10.x, os x v10.11.x, hard disk space for drivers and apps
Mobile Devices Connection	yes

Weight and Dimensions

Depth	12 inches
Height	12 inches
Width	20.9 inches
Net Weight	36.8 pounds
