Brother MFC-J5330DW Service Manual

5-25
Confidential
1.3.13 Transfer of Received FAX Data and/or Equipment's Log (Maintenance mode 53)
< Function >
This function transfers received FAX data to another machine. It is useful when the
machine cannot print received data due to the printing mechanism defective.
This function also transfers the activity report, the communications list, and the
equipment’ log of the machine as fax data.
Notes: - Before carrying out maintenance code 53, update the firmware to the latest
version.
- The number of files that can be transferred at a time
is 99. To transfer 100
files or more, carry out the following procedure more than one time.
- If there are both color and monochrome data in a file to be transferred, the
monochrome data will be transferred first. If the receiver machine does not
support the color function, the sender machine cannot transfer color data,
resulting in an error.
< Operating Procedure >
(1) Press the 5 and 3 keys in this order in the initial stage of the maintenance mode.
The "FAX TRANSFER" appears on the LCD.
- To check the number of received files
, press the 1 key.
The "1.No. Of Jobs" appears on the LCD.
Press the SET key to display the number of received files, just as "No. Of Jobs:
10."
- To transfer the activity report only, press the 2 key.
The "2.Activity" appears.
- To transfer received files (together with the activity report), press the 3 key.
The "3.Documents" appears. Note that if there is no received file, the "No
Documents" appears.
- To transfer the communication list for the latest communication, press the 4 key.
The "4.Com.List (New)" appears.
- To transfer the communication list for the last three errors, press the 5 key.
The "5.Com.List (Err3)" appears.
- To transfer the maintenance information (List of Maintenance mode 77), press
the 6 key.
The "6.MNT77 LIST" appears.
- To transfer the user setting information, press the 7 key.
The "7.USER SETTINGS" appears.
- To transfer the caller ID history, press the 8 key.
The "8.CALLER ID HIST" appears.
- To transfer the outgoing call history, press the 9 key.
The "9.OUTGOING CALL" appears.
- To transfer the radio wave condition list, press the 0 key.
The "0.WLAN DATA" appears.
(2) With one of "2.ACTIVITY," "3.DOCUMENTS," "4.COM.LIST (NEW)," “5.COM.LIST
(ERR3)," "6.MNT77LIST," "7.USER SETTINGS," "8.CALLER ID HIST,"
"9.OUTGOING CALL" and "0.WLAN DATA" being displayed, press the SET key.
The "ENTER NO&OK" appears on the LCD.

Brother MFC-J5330DW Specifications

General

Type	all in one, fax
Color	black
Touch Screen	yes
Display Size	2.7 inches
Tray Capacity	250
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Paper Size	letter, executive, envelope (com-10, dl envelope, monarch), a4, a5, a6 photo 4"x6", 3.5"x5", 5"x7", 5"x8", manual by-pass: 3.5" x 5" to 11" x 17"
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	glossy paper, inkjet paper (coated paper), plain paper, recycled paper
Two-Sided Printing	no
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 2400
Duplex Scan	yes
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3019bk/c/m/y inkvestment super high-yield cartridges, lc3017bk/c/m/y inkvestment super high-yield cartridges
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, google cloud print, mopria print service, usb, wi-fi, wi-fi direct
OS Compatibility	windows vista, 7, 8, 8.1, 10 home, 10 pro, 10 education, 10 enterprise, os x v10.9.5, os x v10.10.x, os x v10.11.x, hard disk space for drivers and apps
Mobile Devices Connection	yes

Weight and Dimensions

Depth	12 inches
Height	12 inches
Width	20.9 inches
Net Weight	36.8 pounds
