Brother MFC-J5330DW Service Manual

Confidential
2-10
3 ERROR INDICATION
To help the user or the service personnel promptly locate the cause of a problem (if
any), the machine incorporates the self-diagnostic functions which display error
messages for equipment errors.
3.1 Error Code
Error
Code
Contents
Refer to
page:
0D00 Paper jam during duplex-printing
The recording papers are fed in reverse on the platen when switchback
drive is started, triggering switchback sensor as paper feeding condition.
2-24
0E00 Defective during duplex-printing
Switchback sensor detects paper feed condition at out of specified timing
during switchback.
2-24
1300 Defective during duplex-printing
Registration sensor detects paper feed condition at out of specified timing
during switchback.
2-25
1500 Paper jam during duplex ejecting
Recording paper is not able to be ejected since it is longer than 840 mm
when ejecting the paper. (The registration sensor stays in the paper
feeding condition during ejecting.)
2-25
1700 Recording paper size error (duplex-printing/duplex-copying)
- Paper width is narrower than 95.5 mm (detection by paper width
sensor)
- Paper length is longer than 245.9 mm (detection by registration sensor)
- Paper length is shorter than 143.5 mm (detection by registration sensor)
2-26
1800 Paper jam during duplex-printing
Registration sensor does not detect paper feed within specified pulse
numbers in the second side paper re-feed.
2-26
2000 Cannot identify a black ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2001 Cannot identify a yellow ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2002 Cannot identify a cyan ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2003 Cannot identify a magenta ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2100 Black ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
2101 Yellow ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
2102 Cyan ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
2103 Magenta ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27

Brother MFC-J5330DW Specifications

General

Type	all in one, fax
Color	black
Touch Screen	yes
Display Size	2.7 inches
Tray Capacity	250
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Paper Size	letter, executive, envelope (com-10, dl envelope, monarch), a4, a5, a6 photo 4"x6", 3.5"x5", 5"x7", 5"x8", manual by-pass: 3.5" x 5" to 11" x 17"
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	glossy paper, inkjet paper (coated paper), plain paper, recycled paper
Two-Sided Printing	no
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 2400
Duplex Scan	yes
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3019bk/c/m/y inkvestment super high-yield cartridges, lc3017bk/c/m/y inkvestment super high-yield cartridges
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, google cloud print, mopria print service, usb, wi-fi, wi-fi direct
OS Compatibility	windows vista, 7, 8, 8.1, 10 home, 10 pro, 10 education, 10 enterprise, os x v10.9.5, os x v10.10.x, os x v10.11.x, hard disk space for drivers and apps
Mobile Devices Connection	yes

Weight and Dimensions

Depth	12 inches
Height	12 inches
Width	20.9 inches
Net Weight	36.8 pounds
