Brother MFC-J5330DW Service Manual

5-38
Confidential
1.3.21 Adjustment of Software Correction for Inclination/Corrugation/Ruled Lines
(Maintenance mode 65)
< Function >
This procedure aligns vertical lines printed in the forward and backward directions of
the head/carriage unit.
If the head/carriage unit, main PCB, or engine-related parts are replaced, you need to
make the adjustment given below.
< Operating Procedure >
(1) On your PC, when using A4-sized paper, save a copy of
“Corrugate_A4_BHB17.prn", and when using letter-sized paper, save a copy of
"Corrugate_LTR_BHB17.prn” to a USB flash memory.
Use“1.3.19 Printout of PRN/JPEG Files in USB Flash Memory (Maintenance mode
61)” in this chapter to print test patterns.
Tip: The test pattern can also be printed by opening "Filedrgs" on your PC and
dragging and dropping the above file onto the Brother Maintenance USB
Printer driver icon.
(2) Press the 6 and 5 keys in this order in the initial stage of the maintenance mode.
The "MAINTENANCE 65" appears on the LCD.
(3) Press the 2 key.
The "A1 No.(1-9)5" appears on the LCD.
(4) Check the A, find which number block shows the most indistinct vertical lines, and
then enter that block number. Then press the SET key.
The "B No.(1-9)5" appears on the LCD.
(5) Wait for the block number to appear for confirmation in the same way. For each of
the printed B to Z, enter the number of the block that shows the most indistinct
vertical lines. Then press the SET key.
Press the key to return to the last block number.
Press the X key to discard the entered information and return the machine to the
initial stage of the maintenance mode.
(6) After entry of the block number for Z, the "OK? 1.YES 2.NO" appears on the LCD.
Press the 1 key to save individual adjustment values and return the machine to the
initial stage of the maintenance mode.
■
Adjustment of Software Correction for Inclination/Corrugation/Ruled Lines Check
Pattern

Brother MFC-J5330DW Specifications

General

Type	all in one, fax
Color	black
Touch Screen	yes
Display Size	2.7 inches
Tray Capacity	250
Output Tray Capacity	100
Automatic Document Feeder Capacity	50 sheets
Paper Size	letter, executive, envelope (com-10, dl envelope, monarch), a4, a5, a6 photo 4"x6", 3.5"x5", 5"x7", 5"x8", manual by-pass: 3.5" x 5" to 11" x 17"
Printing Method	color
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 4800 x 1200
Print Resolution Color	up to 4800 x 1200
Media Types	glossy paper, inkjet paper (coated paper), plain paper, recycled paper
Two-Sided Printing	no
Maximum Number of Pages Per Month	up to 30, 000
Reduction and Enlargement	yes
Photo Printing	yes
Scanner Type	flatbed
Scan Resolution	up to 2400 x 2400
Duplex Scan	yes
Copier Resolution Mono	up to 4800 x 1200
Copier Resolution Color	up to 4800 x 1200
Fax Function	yes
Cartridges	lc3019bk/c/m/y inkvestment super high-yield cartridges, lc3017bk/c/m/y inkvestment super high-yield cartridges
Number Of Cartridges	4
Number of Ink Tanks	0
Internal Memory	yes
Memory Card	no
Network	wired, wireless
Connectivity	apple airprint, brother iprint&scan, google cloud print, mopria print service, usb, wi-fi, wi-fi direct
OS Compatibility	windows vista, 7, 8, 8.1, 10 home, 10 pro, 10 education, 10 enterprise, os x v10.9.5, os x v10.10.x, os x v10.11.x, hard disk space for drivers and apps
Mobile Devices Connection	yes

Weight and Dimensions

Depth	12 inches
Height	12 inches
Width	20.9 inches
Net Weight	36.8 pounds
