Brother MFC-J5330DW Service Manual

Confidential
2-30
■ Error Code 2600
Black ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for specified
times.
Error Code 2601
Yellow ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for specified
times.
Error Code 2602
Cyan ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for specified
times.
Error Code 2603
Magenta ink cartridge reaches its replacement period.
After judging as no ink by the ink remaining sensor, ink discharged for specified
times.
< User Check >
- Replace the ink cartridge.
■ Error Code 2A00
No black ink cartridge loaded.
Detected by the ink cartridge detection sensor.
Error Code 2A01
No yellow ink cartridge loaded.
Detected by the ink cartridge detection sensor.
Error Code 2A02
No cyan ink cartridge loaded.
Detected by the ink cartridge detection sensor.
Error Code 2A03
No magenta ink cartridge loaded.
Detected by the ink cartridge detection sensor.
< User Check >
- Check if incompatible ink cartridge is loaded.
- Reload the ink cartridge.
- Replace the ink cartridge.
Step Cause Solution
1 Ink remaining sensor defective Replace the ink refill ASSY.
2 Main PCB defective Replace the main PCB.
Step Cause Solution
1 Ink cartridge detection sensor
or ink cartridge IC chip PCB
defective
Replace the ink refill ASSY.
2 Main PCB defective Replace the main PCB.
