Brother PR670E - Attaching Fabric Stabilizer

82
Types of embroidery frames/frame holders and their applications
Embroidery type
Embroidering area
Reference
Usage
Embroidery frame holder A
Extra-large embroidery frame 200 mm (H) × 300 mm (W)
(7-7/8 inches (H) × 11-3/4 inches (W))
(Refer to “Hooping the
Fabric” on page 85.)
Use when embroidering connecting characters or patterns,
combined patterns or large embroidery patterns.
Flat frame (optional) 200 mm (H) × 300 mm (W)
(7-7/8 inches (H) × 11-3/4 inches (W))
Consult your nearest
authorized Brother dealer.
Use when embroidering jackets and other thick garments.
Large embroidery frame 130 mm (H) × 180 mm (W)
(5-1/8 inches (H) × 7-1/8 inches (W))
(Refer to “Hooping the
Fabric” on page 85.)
Use when embroidering patterns with a size less than 130 mm (H) ×
180 mm (W) (5-1/8 inches (H) × 7-1/8 inches (W))
Medium embroidery frame 100 mm (H) × 100 mm (W)
(4 inches (H) × 4 inches (W))
(Refer to “6. Hooping the
Fabric in the Embroidery
Frame” on page 42.)
Use when embroidering standard-sized patterns.
Small embroidery frame 40 mm (H) × 60 mm (W)
(1-1/2 inches (H) × 2-3/8 inches (W))
Use when embroidering small-sized patterns, such as nametags.
Embroidery
frame holder B
Quilt frame (optional) 200 mm (H) × 200 mm (W)
(7-7/8 inches (H) × 7-7/8 inches (W))
Consult your nearest
authorized Brother dealer.
Use when embroidering pieces for quilts.
Border frame (optional) 100 mm (H) × 300 mm (W)
(4 inches (H) × 11-3/4 inches (W))
Use when embroidering a long string of characters or patterns.
Sleeve frame (optional) 200 mm (H) × 70 mm (W)
(7-7/8 inches (H) × 2-3/4 inches (W))
Use when embroidering long items such as shirt sleeves.
Embroidery
frame holder C
(optional)
Round frame (optional)
=diameter
100 mm (4 inches)
130 mm (5 inches)
160 mm (6 inches)
Consult your nearest
authorized Brother dealer.
Use when adding a built-in embroidery pattern to a sleeve. Select
the frame appropriate for the size of the pattern.
