166
ELECTRICAL AND IGNITION
ELECTRIC STARTER SERVICING
Install the two thru-bolts. Tighten to a torque of 50
to 65 in. lbs. (5.6 to 7.3 N·m).
Lightly coat the drive gear with Triple-Guard
grease, and install it on the armature shaft. Install
the retaining ring (flat side up) with No. 2 external
retaining ring pliers.
Lightly coat the gear housing bearing with Moly
Lube. Lightly coat the driven gear with Triple-
Guard grease. Install the thrust washer and driven
gear.
Install the weather cover.
If removed, install the spring and spacer (large
diameter up) on the pinion shaft. Secure with
retaining ring. Install bushing and wave washer
(convex side down).
30363
30366
30362
30361
30369
