239
POWERHEAD
REMOVAL
10
REMOVAL
Disconnect the power trim/tilt switch connector.
Remove lower engine cover screws and port and
starboard covers.
Remove flywheel cover and rear shroud.
Remove air temperature sensor from air silencer.
Remove the air silencer.
Remove screw and washer from shift rod lever to
release the lower shift rod.
WARNING
Protect against hazardous fuel spray.
Before starting any fuel system service,
carefully relieve fuel system pressure.
Refer to Relieving Fuel System Pressure
on p. 189.
To prevent accidental starting while ser-
vicing, disconnect the battery cables at
the battery.
005246
1. Lower cover screws 005242
1
1
005248
005272
1. Shift rod screw 005253
1
