373
TRIM AND TILT
REMOVAL AND INSTALLATION
13
REMOVAL AND
INSTALLATION
Removal
Remove port lower engine cover and disconnect
the trim/tilt connectors. Refer to Powerhead
REMOVAL on p. 239.
Remove the rubber grommet from the blue/green
trim/tilt cable connector.
Remove the terminals from the connector by
using a suitable tool to depress the tab. While the
tab is depressed, pull on the wire from the rear of
the connector to release it from the connector.
Separate the trim/tilt unit wires in the braided tube
to permit removal through the hole in the stern
bracket.
Unscrew the manual release valve, raise the unit,
and lock it in place with the tilt support.
Remove the ground wire from the trim/tilt unit.
000686
000687
25078
27381
1. Ground wire 25057
1
