BRP Evinrude E-Tec E115DPLSUC User Manual

OILING SYSTEM
COMPONENTS
203
8
Oil Injection Pump Diagram
1. Oil supply hose
2. Inlet check valve
3. Oil injection pump
4. Injection pump check valve
5. Oil distribution manifold
6. Filter (screen type)
7. Oil pressure sensor
8. Oil distribution hoses to individual cylinders
9. Oil distribution hose to rear manifold
004296r
3
2
1
4
5
6
9
8
7

BRP Evinrude E-Tec E115DPLSUC Specifications

General

Model	E115DPLSUC
Engine Type	2-Stroke
Cylinders	3
Starting System	Electric
Recommended Fuel	87 Octane
Steering	Remote
Oil Injection	Yes
Exhaust	Through Prop
Horsepower	115 hp
Fuel System	Direct Fuel Injection
Shaft Length	20 in. (508 mm)
Displacement	1727 cc
Weight	181 kg (399 lbs)
Alternator Output	12V - 50A
