387
TRIM AND TILT
SERVICING – THREE PISTON SYSTEM
13
Fill the reservoir to the bottom of the fill hole with
Power Trim/Tilt & Steering Fluid. Install and
tighten the reservoir cap. Turn the manual release
valve in until it seats. Cycle the unit up and down
several times to purge air.
Operate the unit to the full UP position, then run
down momentarily to release pressure. Check the
fluid level again and add fluid, if necessary.
Remember that all rods must be completely up to
check the fluid level. Test the unit by performing
the Pressure Leakdown Test on p. 367.
Check the tilt rod bushings. Replace them if they
are worn excessively.
Check the bushings on the bottom of the manifold
body. Replace them if they are worn excessively.
Check system operation in both trim and tilt range.
41859
41885
41888
41878
