PULSE Multi-analyzer System Type 3560-B/C/D/E – Installation and IDAe Hardware126
Specifications – Output Channels, Standard 24-bit and Dyn-X
Standard 24-bit
7537/37-A/39/39-A
Dyn-X
7538/38-A/40/40-A
Output Connector 1 × BNC
Output Coupling DC
Signal Ground Coupling Floating or grounded to chassis
DA Conversion 24-bit
DC Offset ≤1 mV @ 25C° and ≤10 mV @ full temperature range (–60 dB re max. output)
Output Voltage Range 1 μV
peak
– 7 V
peak
Output Impedance 50 Ω
Frequency Range 0 Hz – 25.6 kHz
Frequency Response re 1 kHz ±0.1dB, 1mHz to 25.6kHz
Frequency Accuracy 0.0025%
Waveform 7537, 7537-A 7539, 7539-A 7538, 7538-A 7540, 7540-A
Sine only
Software
determined
Arbitrary waveforms
up to 2Msamples
Sine only
Software
determined
Arbitrary waveforms
up to 2 Msamples
Amplitude Linearity @ 1 kHz Typical
0 to 60 dB below full scale ±0.1 dB
60 to 100 dB below full
scale
±0.2dB
Noise
μV
rms
(nV/√Hz)
Guaranteed Typical Guaranteed Typical
<30 (<188) 20 (125) <30 (<188) 20 (125)
Harmonic and Spurious
Distortion Products
0 – 25.6 kHz < 80 dB re full range output or 1 μV,
whichever is greater
< 80 dB re full range output or 1 μV,
whichever is greater
Absolute Amplitude Precision Guaranteed Guaranteed
@ 23°C, 1 kHz, 1 V
rms
±0.1 dB ±0.1 dB
Crosstalk
between any
generator output
and any channel on
any module
Guaranteed Typical Guaranteed Typical
0 – 2 kHz –100 dB –114dB –100 dB –114 dB
2 kHz – 25.6 kHz –85 dB –110 dB –85 dB –110 dB
Common Mode Rejection Guaranteed Guaranteed
1 Hz – 1 kHz 60dB 60 dB
Max. Common Mode Voltage 5V
peak
, DC – 80 MHz
If common mode voltage exceeds the max. value, care must be taken to limit the
signal ground current in order to prevent damage. Maximum is 100 mA. The
instrument will limit the voltage to the stated max. “without damage” common mode
value
Reconstruction Filter Type Sixth order Butterworth
Attenuation of mirror
frequencies
>80dB
