Appendix B
Specifications of Discontinued Modules
This appendix contains the specifications of the PULSE modules which are no longer avail-
able for sale. Specifications for all other modules can be found in Chapter 11.
10 Mbit LAN Interface Module Type 7533
Input
FREQUENCY RANGE
0 Hz to 12.8 kHz @ 32.768 kHz sampling rate
0 Hz to 25.6 kHz @ 65.536 kHz sampling rate
INPUT CONNECTOR
1 × BNT (ch.0) for Direct/CCLD or tacho
TRANSDUCER SUPPLY VOLTAGES
Supply for Tacho Probe: 6 V typical, max. 60 mA
Constant Current Supply for CCLD: +4mA with a
28 V source
INPUT COUPLING
22.4 Hz High-pass Filter: −0.1 dB @ f
l
= 22.4 Hz,
slope −18 dB/oct., −3dB @ 12Hz
7 Hz Digital High-pass Filter: −0.1 dB @ f
l
= 7 Hz,
slope − 6 dB/oct., −3 dB @ 0.7 Hz (0.7 Hz analog filter
also active)
0.7 Hz High-pass Filter: −0.1 dB @ f
l
= 0.7 Hz, slope
− 6 dB/oct., −3 dB @ 0.07 Hz
DC Direct (f
l
= 0 Hz)
INPUT VOLTAGE RANGE
8 ranges from 7.071 mV to 22.36 V
peak
in 10 dB steps
INPUT IMPEDANCE
Direct: 1MΩ || < 200 pF, typ.
CCLD: > 100 kΩ || < 200 pF, typ.
INPUT PROTECTION
Differential Mode: 50 V
peak
, 35 V
rms
or DC
Common Mode: 15 V
peak
MAX. INDUCED COMMON MODE VOLTAGE
DC − 80 MHz: 1V
peak
COMMON-MODE REJECTION
DC: 50 dB
0 to 1 kHz: 40 dB
CROSSTALK (SOURCE/TERMINATION: 50 Ω)
Between ch. 0 and any channel in other modules
0 to 2 kHz: −100 dB
2 to 12.8 kHz: −85 dB
12.8 kHz to 25.6 kHz: −80 dB
ATTENUATOR LINEARITY
±0.1dB @ 1kHz
ANTIALIASING FILTER
(@ 32.768 and 65.536 kHz sampling rate)
Provides at least 80 dB attenuation of those
frequencies that can cause aliasing
Passband: DC −25.6 kHz @ −0.1dB, slope −18dB/oct.
OVERLOAD DETECTION
Applied before filters
TOTAL HARMONIC DISTORTION
Better than −80 dB ≈ 0.01%
NOISE
(10 Hz − 25.6 kHz) terminated with ≤ 50 Ω
FREQUENCY RESPONSE (f
L
to f
U
re 1 kHz)
7mV to 7V Range: ±0.1 dB
22.36 V Range: ±0.3 dB
