CHAPTER 9
Wireless LAN
105
9.1.3 8.5 dBi Omnidirectional Magnet-based Car Antenna Assembly
Fig.9.3 Left: UL-0232: 8.5 dBi Omni with Magnetic Base, N-Type Male Length 3.5 m (12 feet);
(Order no.: HG2409MGU)
Right: UL-0234: Pigtail-cable for Linksys WET54, RPSMA to N-Type Female. Length:
0.5 m (2 feet); (Order no.: CA-RSPNFA002)
Parts are available from www.hyperlinktech.com
9.2 Additional Accessories
9.2.1 Power Cable from Front-end to Wireless Bridge, AQ-1707
Fig.9.4
Power Cable AQ-1707
This cable powers a wireless bridge from the front-end. Cable length: 0.5 m
Note: This cable is NOT suited for use with the UL-0230, which uses too much power to
be powered from the front-end.
