PULSE Multi-analyzer System Type 3560-B/C/D/E – Installation and IDAe Hardware142
AMPLITUDE LINEARITY (@ 1KHZ)
0 to 40 dB Below Full Scale: ±0.1 dB
40 to 60 dB Below Full Scale: ±0.4 dB
60 to 80 dB Below Full Scale: ±1.0 dB
ABSOLUTE AMPLITUDE PRECISION
±0.1 dB, 2.236 V input range (@ 1 kHz)
GAIN AND PHASE MATCH
To Any Channel in Input Conditioning Module in
Type 3109 or Type 3032: Same as channel-to-
channel match in Type 3109/3032, except for 22.36 V
range
Special Functions
ANALOG AND DIGITAL OFFSET ADJUSTMENT
Offset: −60 dB re max. input
Smart Transducer Support: μLAN communication
according to IEEE 1451.4
The functionality of Type 7533 is dependent on the
DSP software downloaded (part of application
software)
LAN Interface
CONNECTOR
10base2: BNC connector complying with IEEE−802.3
10base2
10baseT: RJ 45 connector complying with IEEE−
802.3 10baseT
PROTOCOL
TCP/IP and TCP/UDP
ACQUISITION PERFORMANCE
Data Transfer rate (No. of Channels × Bandwidth)
from front-end via LAN Interface, per front-end:
150 kHz
Multiframe Control
Must only be connected to other BNC Multiframe
Control Sockets in Type 7533 or 7536
RS−232 Interface
RS−232 OUTPUT
Fulfils EIA−562 (electrical) and EIA−574 (mechanical)
OUTPUT SUPPLY
5 V, max. 50 mA
Aux. I/O
NUMBER OF INPUT CHANNELS
12
*
INPUT CONNECTOR
1 × High density 20-pole D-sub
SAMPLING RATE
10 samples per second (no internal anti-aliasing filters)
INPUT CONNECTIONS
Single-ended
INPUT VOLTAGE RANGES
Six input ranges from 0.1 V to 31.6 V in 10 dB steps
INPUT PROTECTION
50 V
INPUT IMPEDANCE
1MΩ || < 200 pF
Range Equivalent Input Noise
7.071 mV 3 μV
rms
22.36 mV 3 μV
rms
70.71 mV 5 μV
rms
223.6 mV 10 μV
rms
707.1 mV 31 μV
rms
2.236 V 100 μV
rms
7.071 V 316 μV
rms
22.36 V 1 mV
rms
*.16 input channels (12 currently supported in software) plus 2 output
channels that are not currently supported in software
