12
(67)
BRUKER
BVT3000
Version
0
03
Descrip
tion
T
able
1.1.
Flow
rate
versus
command
Decimal
combination
Combination
ABC
D
Flow
rate
(l
/
h)
0
0000
0
1
0001
135
2
0010
270
3
0011
400
4
0100
535
5
0101
670
6
0110
800
7
0111
935
8
1000
1070
9
1001
1200
10
1010
1335
11
1011
1470
12
1100
1600
13
1101
1735
14
1110
1870
15
1111
2000
11
13
Table of Contents
Table of Contents
3
Contents
3
Table of Contents
3
Index
5
1 Description
7
Introduction
7
BVT3000 Main Components
8
Figure 1.1. BVT3000 Block Diagram
8
Parts Location
9
Principle of Operation
9
Figure 1.2. Parts Location
9
The Front Panel
10
Figure 1.3. BVT3000 Front Panel
10
Gas Flow Circuit
11
Figure 1.4. Gas Flow Circuit
11
Setting up the Gas Flow
11
Table 1.1. Flow Rate Versus Command
12
Front Panel Connectors
13
Figure 1.5. Heater Connector (Front View)
13
Heater Connector
13
Table 1.2. Heater Connector Pin Assignment
13
Figure 1.6. Pt100 Connector (Front View)
14
Pt100 Connector
14
Table 1.3. Pt100 Connector Pin Assignment
14
Figure 1.7. Thermocouple Connector (Front View)
15
Table 1.4. Thermocouple T Pin Assignment
15
Thermocouple Connector
15
Figure 1.8. RS232 Male Connector (Front View)
16
RS232 Connector
16
Table 1.5. RS232 Connector Pin Assignment
16
BCU05 Connector
17
Figure 1.10. BCU05 Connector
17
Figure 1.9. N2 Connector (Front View)
17
N2 Connector (Option)
17
Table 1.6. Evaporator Connector Pin Assignment
17
Table 1.7. BCU05 Connector Pin Assignment
17
BVTB 3500 Connector
18
Figure 1.11. BVTB 3500 Connector (Front View)
18
Table 1.8. BVTB 3500 Connector Pin Assignment
18
2 Options
19
Auxiliary Sensors Module - BASM
19
Figure 2.1. BASM Front View
19
Manual Command Module - BMCM
20
Low Temperature Options
20
Figure 2.2. BMCM Front View
20
Liquid Nitrogen Exchanger
21
Exchanger Presentation
21
Liquid Nitrogen Evaporator
22
Evaporator Presentation
22
BCU05 Gas Cooler
23
3 Configuration
25
Sensor Selection
25
Eurotherm 902 Configuration
25
Table 3.1. Eurotherm Sensor Code
26
4 Remote Interface Control
27
Microcontroller Interface
27
Digital Interface Specifications
27
Commands and Communication Protocol
28
Control Characters
28
Table 4.1. Control Characters
28
List of Commands
29
Table 4.2. List of Commands
29
Rs232 Link Characteristics
30
Rs232 Cable
30
Authorised Functions
30
Figure 4.1. RS232 Cable
30
Table 4.3. Authorised Commands
31
AF (Air Flow)
32
CM (Check Memory for Test Only)
33
CO (Communications Speed)
34
Description
34
DL (Download)
35
DT (DAC Check for Test Only)
36
Error Status)
37
Table 4.4. Error Status Description
37
HP (Heater Power)
38
IS (Interface Status)
39
NH (Nitrogen Heater)
40
NP (Nitrogen Heater Power)
41
P1 (Port 1 for Test Only)
42
Table 4.6. Port 1 Definition
42
P2 (Port 2 for Test Only)
43
Table 4.7. Port2 Definition
43
P3 (Port 3 for Test Only)
44
Table 4.8. Port3 Definition
44
Figure 4.2. Valve Jumpers Settings
45
P4 (Port 4 for Test Only)
45
Table 4.9. Port 4 Definition
45
RB (Read BBIS)
46
Software Version)
47
WB (Write BBIS)
48
Table 4.10. Record Format
49
WR (Write Record)
49
XR (Extract a Record)
50
5 Technical Specifications
51
Specifications
51
Security Fuses
52
6 Schematics
53
Figures
63
Tables
