Bruker BVT3000 - 1.7.3 Thermocouple connector

BVT3000 Version 003 BRUKER 15 (67)
Front panel connectors
Thermocouple connector 1.7.3
Figure 1.7. Thermocouple connector (Front view)
Table 1.4. Thermocouple T pin assignment
Other thermocouple connectors have the same pin assignement.
PIN SIGNAL
1 (Cu) Shield
2 (Cu) Thermocouple +
3 (Co.) Thermocouple -
T
CP
CONST -
1
2
3
+
