3.6 Transporting the humidifier
NOTICE!
Risk of property damage from the humidifier tip-
ping over!
When moving the humidifier back and forth, there is a
risk of the device tipping over. This can lead to
damage to the device or subsurface.
– Whenever possible, move the humidifier along its
longitudinal axis.
– Before changing the installation location, always
empty the water tank.
The humidifier has 4 rollers on the bottom. This allows reposi-
tioning of the device by pulling or pushing. Observe the following
when the humidifier's installation location is changed:
n Whenever possible, move the humidifier along its longitudinal
axis (Fig. 7/arrow). To do so, grasp the humidifier at the green
marked area (Fig. 7).
n If the humidifier is moved back and forth, grasp it underneath
as well (Fig. 8).
Fig. 7: Moving the humidifier
Fig. 8: Moving the humidifier back
and forth
Transport and storage
Evaporation Humidifier B500 Professional 23
