Brune B500 - 8.4.2 Replacing the activated charcoal cleaning filter

In addition to the bio-filter used as standard, an additional activated
charcoal cleaning filter can be used for air filtration. This binds
organic pollutants and unwanted odors. The lifetime of the acti-
vated carbon cleaning filter is approximately 6 months, but this
depends largely on the room air pollution.
The activated charcoal cleaning filter is mounted directly above the
evaporation filter. For this, the clamping bracket of the evaporation
filter must be removed and replaced by the bracket to be ordered
(article number 1413/500). It differs from the standard bracket in
that it has two additional retaining lugs for the activated charcoal
cleaning filter (Fig. 60/1). Proceed as described in
Ä Chapter
8.4.2 “Replacing the activated charcoal cleaning filter”
on page 64 to replace the activated charcoal cleaning filter.
8.4.2 Replacing the activated charcoal cleaning filter
Personnel:
n
Operator
WARNING!
Risk of electrical shock if the power plug is not
disconnected!
1. Switch off the humidifier and disconnect the power plug.
2. Lift the cover of the humidifier upwards and place it to the
side (Fig. 61).
Fig. 59: Activated charcoal cleaning
filter
Fig. 60: Clamping bracket for acti-
vated charcoal cleaning filter
Fig. 61: Removing the cover
Accessories
Evaporation Humidifier B500 Professional64
