B Parts list
WARNING!
Risk of injury from disassembling the humidifier!
The illustrations and parts list below are only intended
for specialized retailers. Unauthorized disassembling
of the humidifier may cause serious injury.
– Never disassemble the device on your own.
– Only perform the repairs described in this manual.
– For problems where the solution is not described in
this manual, contact the local specialized retailer.
Standard version
No. Name No. Name
1101 Housing, upper part, white us1377 Board cover
1102 Housing, upper part, light gray 1380 Motherboard 115
1104/500 Housing, upper part anthracite 1385 Additional board for multi-speed fan
1149 “Filter replacement” sign 1401 Water distribution
1150 “Fill here” sign 1406/1 Remote control without batteries
1151 Fill flap, white 1411 Filler rods without rib (6)
1152 Fill flap, light gray 1412 Filler rods without rib (4)
1154 Fill flap, anthracite 1413 Clamping bracket with 2 lugs
1201 Housing, lower part, white 1500S Fan, complete with motor, safety guard
and fastening material
1202 Housing, lower part, light gray 1507 Safety guard for fan
1204/500 Housing, lower part, anthracite 1508 Sheet metal screw M 4.2 x 19 A2 (4)
1251 Impact sleeve (4) 1520 Rubber metal buffer M 4, stainless steel
(3)
1252 Castors (4) 1521 Pump, complete
1301 Center plate, white 1522/1 Pump motor incl. cable 0.3 m and
pump ventilator
1302 Center plate, light gray 1523 Pump body
1304/500 Center plate, anthracite 1524 Pump cover plate
1311 Shaft 1525 Pump impeller blade
1312/500 Shaft cover 1526 Y piece
1326 Electrode rods (set = 7) with head 1529 Pump hose, crystal clear (2)
1339 Cable harness 1551 Cylinder head screw M 4 x 10
Parts list
Evaporation Humidifier B500 Professional86
