5.
WARNING!
Danger of poisoning and damage to property
from careless removal of the UV lamp!
Carefully pull out the UV lamp at the connection cable
(Fig. 74).
6. Only touch the UV lamp at its blue end pieces. Remove the
UV lamp connection cable (Fig. 75).
7. Grasp the new UV lamp on the end caps and unpack it.
8. Attach the connection cable to the new UV lamp.
9. Carefully insert the UV lamp into the quartz glass body.
10. Replace the control panel and affix it using the four screws.
11. Replace the device cover.
8.7 Safety collecting basin
Order numbers:
– Safety collecting basin, white: 1752.1
– Safety collecting basin, gray: 1752.2
– Safety collecting basin, anthracite: 1752.4
The safety collecting basin (Fig. 76/1) is placed below the Evapora-
tion Humidifier B500. It collects any excess water during water
leakage.
Fig. 74: Pulling out the UV lamp
Fig. 75: Releasing the connection
cable
Fig. 76: Safety collecting basin
Accessories
