Brune B500 - 11 Technical data

11 Technical data
11.1 Dimensions and weight
Data Value Unit
Weight (empty) approx. 24 /
53
kg / lbs
Width 755 / 29.7 mm / in
Height 620 / 24.4 mm / in
Depth 365 / 14.4 mm / in
Water tank volume approx. 50 /
13.2
l / US gal
11.2 Connection values
Data Value Unit
Voltage 230 V
Frequency 50 Hz
Power consumption, maximum 130 W
Fuse, at least 10 A
Maximum water pressure when con-
necting to the public water supply
1 MPa
Minimum water pressure when con-
necting to the public water supply
0 MPa
11.3 Performance data
Data Value Unit
Air output 900 / 3962 m³/h /
gal/min
Evaporation performance 2.6 / 16.5 l/h / US
gpd
Evaporation filter surface 3.5 / 37.7 m² / sq ft
11.4 Operating conditions
Data Value Unit
Temperature range 10 – 40 / 50
– 104
°C / °F
Electrical
Environment
Technical data
Evaporation Humidifier B500 Professional78
