Electrical Connection
5
ekr CON 600, ekr CON 600 net – Master-Slave Guiding with Sensor Positioner 15/47
5.3 Connector Assignment
The assignment of the connectors at the ekr CON 600, ekr CON
600 net controller housing depends on the number of edge
sensors used for the Master-Slave Guiding.
5.3.1 Master-Slave Guiding with Two Edge Sensors
5.3.1.1 Guiding to the Left Web Edge
Application with
ekrCON600 controller
Fig.2: Connector assignment on the ekr CON 600 controller
Apllication with
ekrCON600net controller
Fig.3: Connector assignment on the ekr CON 600 net controller
Connector Assignment
Component Web of Material Connector
ekrcommander X101
Sensor1 SLAVE web X102
Sensor3 MASTER web X100
