SMART MATRIX MTC Operation
SMART MATRIX MTC 2 - 3
1 – Navigation inside the Selected Window (STD)
Turn the selector to “Point” in sequence the various items of the window
(STD → TARGET → DELAY START → DELAY COUNT→ SENSITIVITY→ DELAY STOP
→ CORRECTION→ RECOVERY).
The frame indicates the “Pointed” field.
Î Î Î
Click to “Select” the pointed item. The field name will be shown in reverse and the symbols:
appear to the right of the field value:
Example:
TARGET field selected (reverse)
Turn the selector either to Clockwise or to Counter-clockwise direction to select the desired
option (in this case the numerical value chosen)
Example:
New value of TARGET = 1200
Once you have set the desired value (e.g. 1200), click to confirm.
Example:
TARGET field no more selected
Turn the selector to select a new field and so on…
