Entering system settings (Service menu – Settings)
6
RC35 programming unit - Technical specifications are subject to change without prior notice.
38
6.6 RC35 calibration
Calibrating the displayed room temperature (Calibration)
If there is a separate thermometer near the programming unit, it may show a different room
temperature to that shown on the programming unit. You can use this function to adjust
the programming unit to match the thermometer (i.e. “calibrate” the programming unit).
Before calibrating the room temperature, consider the following:
– Is the thermometer more accurate than the programming unit?
– Is the thermometer located close to programming unit so that they are both subject to
the same heat influences (e.g. sunlight, fireplace)?
Example: if the thermometer is showing a temperature 0.5°C higher than the programming
unit, enter "+0.5 K" as the calibration value.
z Turn the rotary selector anti-clockwise until RC35 cali-
bration is selected (marked with
B).
z Press to select RC35 calibration.
The menu SETTINGS \ CALIB. RC35 is opened.
Menu item
Input range
Factory setting in bold
Other information
Calibration of the room
temperature:
0.0K
-5.0K to +5.0K
Table 15 Navigator for Service menu SETTINGS \ CALIB. RC35
A thermometer may show temperature changes more slowly or more quickly
than the programming unit.
z Never calibrate the programming unit when your heating system is in the
process of cooling down or heating up.
domestic hot water
heating circuit 1
solar data
RC35 calibration
SERVICE\SETTINGS
B

Buderus RC35 Specifications

General

Display	LCD
Temperature Control	Yes
Weather Compensation	Yes
Communication	EMS Bus
Mounting	Wall-mounted
Voltage	24 V
Temperature range	5°C to 30°C
Accuracy	±0.5°C
Protection class	IP20
Weight	0.3 kg
Power consumption	2 W
Switching current	Not applicable
Ambient temperature	0°C to 45°C
