Safety instructions and symbols
1
RC35 programming unit - Technical specifications are subject to change without prior notice.
5
1.2 Explanation of symbols
The terms indicate the seriousness of the ensuing risk if measures for minimising damage
are not taken.
– Caution means that minor property damage may occur.
– Warning means that minor injury or severe property damage may occur.
– Danger means that severe injury may occur. Very serious cases may result in death.
Notes contain important information for situations in which there is no risk to the user or
the device.
Display text: Words appearing on the display are shown in bold
in the text.
Example: USER MENU
Action sequences: Each step in an action sequence is marked with a bullet point.
Example: Press .
If action sequences have more than two steps and the order of the steps is important, they
are numbered (1., 2., ...).
Safety instructions throughout the text are indicated by a warning triangle in-
side a rectangular frame.
Notes throughout the text are identified with this symbol. They are bounded by
horizontal lines above and below the text.
Note on using this manual: Section 4.2 "Introduction to the Service menu"
explains in detail the steps needed for programming all the settings in the Serv-
ice menu. In the sections which come after it, programming is only explained in
outline.
standard display
operation modes
switching programme
sum./win. threshold
USER MENU
To Next Page
