Information about the product
2
RC35 programming unit - Technical specifications are subject to change without prior notice.
7
2.4 Specifications
Temperature sensor characteristics
When measuring temperature sensor resistance, observe the following requirements:
– Isolate the system before measuring.
– Measure the resistance at the cable ends.
– The resistances represent mean values and are subject to tolerances.
Unit RC35
Power supply via bus system V16 V DC
Power consumption W0.3
Power consumption with backlighting W0.6
Dimensions (width/height/depth) mm 150/90/32
Weight g233
Operating temperature °C 0 to +50
Storage temperature °C 0 to +70
Relative humidity %0 to 90
CE marking
Table 1 Specifications for the RC35 programming unit
Outside temperature sensor
Boiler/flow temperature sensor
DHW temperature sensor
°C kΩ °C kΩ °C kΩ
-20 96.358
10 19.872 60 2.49
-15 72.51
16 15.699 65 2.084
-10 55.054
20 12.488 70 1.753
-5 42.162
25 10.001 75 1.481
±0 32.556
30 8.060 80 1.256
525.339
35 6.535 85 1.070
10 19.872
40 5.331 90 0.915
15 15.699
45 4.372 95 0.786
20 12.488
50 3.606 100 0.677
25 10.001
55 2.989
30 8.060
Table 2 Resistances of the temperature sensors, for EMS only
