Power Trim
Your Bukh drive is equipped with a hydraulic trim
system, Power Trim, that allows you to adjust the
angle of the drive with respect to the transom from the
helm station. The angle of the drive effects the boat's
passage through the water and other characteristics,
e.g. improved acceleration to planing and planing with
a lower throttle opening. Trimming can also be used to
give a more gentle passage in short seas.
Trim Ranges
To be able to use the information on the trim
instrument, it is important to be aware of the three trim
ranges and the way they are used.
Trim range
The trim range are used to provide the best comfort
when driving – from starting to top speed.
Beach range
The beach range is used for driving at low speed in
shallow water or where the depth is unknown.
The highest permitted engine speed when in the beach
range is 1500 rpm.
IMPORTANT:
Make sure the
drive's coolant inlet is never trimmed out
of the water when operating in the beach range.
Lift range
The lift range is never used when sailing. It lifts the
drive to maximum height and is used for e.g.
transporting the boat on a trailer. Power Trim has an
automatic stop that turns off the power when the end
position is reached. The catch is released
automatically when the stern drive is trimmed down.
WARNING!
The engine must not be run with the drive in the “lift”
range.
Instruments and Controls
30 47708085 11-2016 © Bukh
