Controls
This section describes the controls Bukh sells for your
engine. Contact your dealer if your boat is equipped
with controls other than those described here, and you
feel uncertain about their function.
A single-lever control operates both gearshift and
throttle functions with the same lever.
The engine can only be started with the control lever
in the neutral position.
N = Neutral position. Reverse gear/drive disengaged
and engine at idle.
F = Reverse gear/drive engaged for forward motion.
R = Reverse gear/drive engaged for rearward
motion.
T = Engine rpm control (throttle).
Engine and drive features are controlled with push
buttons on the control. The buttons and functions
available depend on the installation.
1 STATION
The button lamp is lit if the helm station is active and
lit. Refer to
Operation, page 61 for further
information.
2 CRUISE CONTROL
Switch on cruise control by pressing the button.
Fine tune the locked engine speed by increasing (+)
or reducing (-) engine rpm with the button at the
other side of the control.
3 LOW SPEED (Optional)
See Optional, page 40 for information.
4 THROTTLE ONLY
Disconnects the shift function so that the control
lever only affects engine speed; refer to
"Disengaging shift function" in this chapter for
further information.
5 SINGLE LEVER
Switch on the single-lever function by pressing the
button. The lever that is moved from its position first
becomes the control lever for both engines. The
other control lever has no function as long as the
single-lever function is activated. The button lamp
lights up to show that the function is active. Exit the
single-lever function by pressing the button again.
STATION
THROTTLE
ONLY
CRUISE
CONTROL
SINGLE
LEVER
LOW
SPEED
TRIM
Assist
1
2
3
4
5
6
7
8
10
9
P0013213
Instruments and Controls
47708085 11-2016 © Bukh 35
