burmeier Dali - LED Controller; LED Power Pack

3.2.1 LED Power Pack
3.2.2 LED Controller
LED colour State Duration Meaning
yellow lights up permanently Enabling the voltage
for the control unit.
Functions can be per-
formed
green lights up permanently Power pack is in idle
mode
LED off does not light up Power pack is:
• not connected to
the mains
• defective
• overheated
LED colour State Duration Meaning
green lights up permanently Control unit is supplied
with voltage
orange lights up 4 s Pairing was successful
orange flashes 4x 0.5 s on/ 0.5 s off Pairing was not suc-
cessful
orange lights up 2 s Function was success-
ful
orange flashes 2x 0.5 s on/ 0.5 s off Function was not suc-
cessful
orange lights up permanently Fatal error
orange flashes for 20 s 0.1 s on/ 0.4 s off Control unit is in pair-
ing mode with the
handset
LED off does not light up No power supply to
control unit
Operation
Part C: Care staff and residents 15
