4.5.10 Electrical data: Dali wash
Control unit
Type: CBSTI01-V2
Compatible with: Bluetooth and cabled handset
Operating voltage Through SMPS 12-type external power supply unit
Output current 8 A
Duty cycle Intermittent duty: 2 min ON / 18 min OFF
Protection category IPX6
Classification Protection class 2
Radio transmitter characteristics (applies to control unit CBSTI01-V2 and Bluetooth
handset HBSTI)
Frequency band of transmission 2,400 MHz - 2,485 MHz
Type BLUETOOTH Low Energy BLE 4.2
Modulation GFSK
Maximum effective radiated power (ERP) 10 dBm
Switch mode power supply
Type SMPS12
Input voltage 230 VAC (-15% / +10%)
Standby current consumption < 0.5W
Current input 1.8 a max.
Output voltage 32 VDC
Output current 4.5 A
Duty cycle Intermittent duty: 2 min ON / 18 min OFF
Protection category IPX4
Classification Protection class 2
