4.5 Technical Data
4.5.1 Type plate
Mattress base dimensions (WxL) External dimensions (WxL)
90 x 200 cm (wooden or metal mattress base) 102 x 218 cm
You can find the type plate on the bed frame at the head end. The type plate contains the
following information:
Type plate, example Type plate (electrical data), example
Explanation of the graphical symbols used:
Model Bed model
Material Material variant (if applicable)
Version Variant (if applicable)
Item number (Kmat)
Order number
Date of manufacture (week/year)
The article is a medical device
Device with type BF applied part in accordance with IEC 601-1 (special
protection against electric shock)
Product Description
Part A: General Information 9
