WARNING
3.
The second person now removes the
locking pin [a]. To do so, swivel the
curved clip away and draw the bolt and
pin, together with the clip, out of the back-
rest motor lifting pipe [b].
Risk of injury
If the backrest falls unchecked, the resident and/or the second member of staff could
be injured!
1.
Manual CPR release of the backrest must be carried out by two people!
In the event of power supply outages or electrical drive system failures, the raised backrest
can be lowered by hand. Two carers are absolutely necessary to carry this out!
1.
Release the load on the backrest before carrying out the CPR release procedure.
2.
To do so, the first person raises the backrest slightly by gripping the outside edge of the
head section and holds the backrest in this position.
4.
The motor is now separated from the backrest and will fall off.
5.
The first carer then carefully lowers the backrest.
To return the bed to its original state:
Operation
Part C: Care staff and residents 27
