[1] Foot end chassis [2] Safety side release buttons (4x)
[3] Lower leg rest [4] Thigh rest
[5] Handset [6] Triangular grab handle
[7] Backrest [8] Patient lifting pole
[9] Head end chassis [10] Mattress retainers (4x)
[11] Guide rails (4x) [12] Lifting pole sleeves (2x)
[13] Castors (4x) [14] Control unit (concealed in the pic-
ture)
[15] Drive motors for backrest and
thigh rest (concealed in picture)
[16] Safety side bars
[17] Mattress base frame [18] Brake pedal
