ATTENTION
Risk of injury
Failure to heed these warnings may result in injury and damage to property due to improp-
erly assembled, falling safety side bars.
•
After installing each safety side bar, check that it is correctly locked into the holding devi-
ces.
•
Test the function to check that the safety sides are correctly fitted. For more information
on operating the safety side, see chapter
Part C: Safety side » 21
Important:The guide rails must be diagonal to each other before starting the assembly work
(see picture). To ensure this, raise the guide rail at the head end and lower the guide rail at
the foot end.
Start with the chassis headboard on the right-hand side of the bed and proceed as follows:
•
Attach one end of the wooden safety side bar to the lower holding fixture [a].
•
Please note: The recess on the safety side bar must face inwards and the roun-
ded side of the bar must face upwards.
Assembling the Care Bed
Part B: Operator and Technical Personnel 15
