14.4 BWT MINISTIL P-280, P-670, P-930
MINISTIL Jumbo P, devices for rent P-280 P-670 P-930
Flow rate max. m
3
/h 12 22 36
Capacity at 10°f/ 20°f m
3
50/25 120/60 166/84
Capacity at 10°d/ 20°d m
3
28/14 66/33 92/46
Max. operating pressure at 20°C/30°C bar 6/5 6/5 6/5
Max. operating pressure at 40°C/50°C bar 4/3 4/3 4/3
Max. operating temperature °C 50 50 50
Pressure loss at max.power approx. bar 1,2 1,2 1,2
Mains connection V/Hz 230/50 230/50 230/50
Hydraulic connection Ø 63 63 63
Shipping-/operational weight kg 350/380 750/1000 900/1250
Order no. for rent devices complete 114228 144158 114247
Accessories for rent devices
Order no. complete connection kit for rent 145378
Spare parts
Order no. connection elbow 90°, top side Ø63mm 144999
Order no. adapter screw connection D63-Storz 280–930 145399
Order no. closing cap, Ø63mm 145212
Order no. connection adapter, Ø63mm–1" 144400
14.5 BWT MINISTIL control heads of the 1iD-6iD series
MINISTIL connection head complete type 1iD type 2iD type 3iD type 5iD type 6iD
Conductivity measurement and display of pure water X X X X X
Adjustable conductivity alarm (stepless) X X X X X
Wi-Fi compatibility X X X X X
Flow measurement and display X X X X X
Conductivity measurement and raw water display X X
Capacity display XX
Potential-free changeover contact (max. 24V/1A) X X X
AC adapter; 230V AC/9V DC (7.2W) X X X X
AC adapter; 230V AC/24V DC (15W) X
Solenoid valve ¾", 24V DC X
Temperature measurement & display X
Pressure measurement & display X
Mains connection V/Hz 230/50
Hydraulic connection inch 3/4“
Dimensions (WxDxH) mm 175/210/70
Shipping weight kg 1,6
Item and order number 152371 152372 152373 152375 152376
Info: BWT MINISTIL 1iD to 6iD head types are suitable for cartridge types P-6, P-12, P24, P-21, P-41, P-61, P-101.
