String Function (Units)
$BD:xx,CMD:MON,CH:X,PAR:VSET Read out VSET value ( XXXX.X V )
$BD:xx,CMD:MON,CH:X,PAR:VMIN Read out VSET minimum value ( 0 V)
$BD:xx,CMD:MON,CH:X,PAR:VMAX Read out VSET maximum value ( 8000.0 V )
$BD:xx,CMD:MON,CH:X,PAR:VDEC Read out VSET number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:VMON Read out VMON value ( XXXX.X V )
$BD:xx,CMD:MON,CH:X,PAR:ISET Read out ISET value ( XXXX.XX µA )
$BD:xx,CMD:MON,CH:X,PAR:IMIN Read out ISET minimum value ( 0 µA )
$BD:xx,CMD:MON,CH:X,PAR:IMAX Read out ISET maximum value ( 3000.00 µA )
$BD:xx,CMD:MON,CH:X,PAR:ISDEC Read out ISET number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:IMON Read out IMON value ( XXXX.XX µA )
$BD:xx,CMD:MON,CH:X,PAR:IMRANGE Read out IMON RANGE value ( HIGH / LOW )
$BD:xx,CMD:MON,CH:X,PAR:IMDEC Read out IMON number of decimal digits (2 HR, 3 LR)
$BD:xx,CMD:MON,CH:X,PAR:MAXV Read out MAXVSET value ( XXXX V )
$BD:xx,CMD:MON,CH:X,PAR:MVMIN Read out MAXVSET minimum value ( 0 V )
$BD:xx,CMD:MON,CH:X,PAR:MVMAX Read out MAXVSET maximum value ( 8100 V )
$BD:xx,CMD:MON,CH:X,PAR:MVDEC Read out MAXVSET number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:RUP Read out RAMP UP value ( XXX V/S )
$BD:xx,CMD:MON,CH:X,PAR:RUPMIN Read out RAMP UP minimum value ( 1 V/S )
$BD:xx,CMD:MON,CH:X,PAR:RUPMAX Read out RAMP UP maximum value ( 500 V/S )
$BD:xx,CMD:MON,CH:X,PAR:RUPDEC Read out RAMP UP number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:RDWN Read out RAMP DOWN value ( XXX V/S )
$BD:xx,CMD:MON,CH:X,PAR:RDWMIN Read out RAMP DOWN minimum value ( 1 V/S )
$BD:xx,CMD:MON,CH:X,PAR:RDWMAX Read out RAMP DOWN maximum value (500 V/S)
$BD:xx,CMD:MON,CH:X,PAR:RDWDEC Read out RAMP DOWN number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:TRIP Read out TRIP time value ( XXXX.X S )
$BD:xx,CMD:MON,CH:X,PAR:TRIPMIN Read out TRIP time minimum value ( 0 S )
$BD:xx,CMD:MON,CH:X,PAR:TRIPMAX Read out TRIP time maximum value ( 1000.0 S )
$BD:xx,CMD:MON,CH:X,PAR:TRIPDEC Read out TRIP time number of decimal digits
$BD:xx,CMD:MON,CH:X,PAR:PDWN Read out POWER DOWN value ( RAMP / KILL )
$BD:xx,CMD:MON,CH:X,PAR:POL Read out POLARITY value ( '+' / '-' )
$BD:xx,CMD:MON,CH:X,PAR:STAT Read out Channel status value ( XXXXX )
3.5.3.1. Meaning of STATUS bits (value read in decimal Format)
Bit Function
Bit 0 → ON 1 : ON 0 : OFF
