U
SER
’
S
G
UIDE
— 57
Degree of Pitch
If the degree of pitch is 30.45°, what is the percent Grade, Slope
and Pitch in Inches?
KEYSTROKE DISPLAY
o o 0.
3 0 • 4 5 p PTCH 30.45°
p %GRD 58.78702
p SLP 0.58787
p PTCH 7-1/16 INCH
Note: To convert Pitch in Inches: Simply enter the Pitch in Inches first (e.g.,
7 i p
),
then continuously press the
p
key to calculate the pitch conversions, as above.
Percent Grade
If the Percent Grade is 47.25%, what is the Slope, Pitch in Inches,
and Degree of Pitch?
KEYSTROKE DISPLAY
o o 0.
4 7 • 2 5 %* p %GRD 47.25
p SLP 0.4725
p PTCH 5-11/16 INCH
p PTCH 25.29°
*For entering Percent Grade, you need to label the value with the percent key.
Pitch Ratio or Slope
If the Pitch Ratio is 0.65, what is the Pitch in Inches, Degree of Pitch,
and Percent Grade?
KEYSTROKE DISPLAY
o o 0.
• 6 5 Ç* p
(Slope)
SLP 0.65
p PTCH 7-13/16 INCH
p PTCH 33.02°
p %GRD 65.
*For entering Pitch Ratio, you must press the
Ç
key first.
