Calix E5-400 User Manual

44
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© 2001-2009 Calix. All Rights Reserved.
E5-400 Specifications
E5-400 System Specifications
Dimensions
H: 1.75-inches
W: 17.5-inches
D: 11.25-inches
Weight
8.5-lbs.
10-lbs. with fan tray installed
Voltage
-48 VDC redundant power supply
(-40 to -60 VDC)
Alarm
Interfaces
Wire-wrap pins on the rear panel
Watts
120 Watts maximum
Fusing
5 Amps (A and B Feeds)
Fiber/Copper
Interfaces
(12) GE SFP Ports
(2) 10GE SFP+ Ports
(2) 10GE XFP Ports
Management
Interfaces
CMS
Web Interface
Command Line (CLI)
Fan Tray
Controls
10/100 BaseT Ethernet Management
Interface
Alarm Cut-off (ACO) and Alarm LEDs
(Critical, Major, and Minor)
Alarm
Input/Output
4 User definable environmental alarms
Critical, Major, and Minor Audible and
Visual Alarms
Fan Tray
4 fans mounted in line.
