The Calix E5-400 rear panel
The E5-400 rear panel is equipped with the following interfaces:
 Chassis ground
 Dual power input terminal block (A/B)
 Alarm interface panel
-48V RTN A
-48V A
-48V RTN B
-48V B
5493
A/B Power Input
Chassis Ground Lugs
Chassis Ground Lugs
Alarm Interface
Panel
