Install T1 labels
Calix outdoor cabinets ship with labels to indicate which
slots on the copper protection blocks are connected to a
T1 card. Use these labels to alert field technicians to the
possible presence of powered T1 lines at a protection
block.
The figure shows the labels for slot 1 and where you would
apply them to the copper protection block.
