1) Fasten the guide arm to the top of the door frame, perpendicularly to the transmission guide. Use the supplied rivets and other
suitable bolts and screws.
5.7 Fastening the guide arm to the transmission guide
2) Release the traction slide by turning the small level clockwise.
Move the slide towards the door and hook it onto the guide arm with the supplied bolt.
