Transmitters
Radiofrequency card
Electrical board
8 Activating the remote control
Connect the radiofrequency card to the electrical board AFTER SHUTTING OFF THE POWER (or disconnecting the batteries).
N.B.: The circuit board recognizes the readiofrequency card only when it is running in electrical power.
Connect the antenna with the RG58 cable to the apposite terminals on the board.
1 - Antenna
2 - Radio frequency
See attached instructions
