Camus Hydronics Avenger Series - Page 81

76
JACKET ASSMEBLY
ITEM
#
FIGURE (S)
Part Description Part Number
Avenger Models
All
1000
1500
2000
2500
3000
3500
4000
1 A Primary Heat Exchanger
651-00390-000 x
651-00100-000 x
651-00115-000 x x
651-00394-000 x
651-00391-000 x x
2 A EMKA Latch With Insert RH 043-00061-000 x
3 A HX Base
003-00249-000 x
003-00251-000 x
003-00250-000 x x x x x
4 A Electrical Box Assembly 848-02021-000 x
5 A Jacket Frame
446-01750-000 x
446-01777-000 x
446-01783-000 x x
446-01776-000 x x x
6 A Junction Box Assembly 125-00555-000 x
7 A Back Panel, Outer Jacket
136-00301-000 x
136-00302-000 x
136-04345-000 x x
136-04355-000 x
136-04338-000 x x
8 A Panel Bracket, Top Side
527-00604-000 x
527-00608-000 x
527-00607-000 x x x x x
9 A EMKA Latch With Insert LH 043-00062-000 x
10 A Panel Bracket, Top Front
527-00605-000 x x
527-00609-000 x x
527-00606-000 x x x
11 A Front Bracket, Mid
083-00027-000 x x
083-00028-000 x x x x x
12 A Front Panel , Outer Jacket (Bottom)
125-90026-000 x x
125-90031-000 x x
125-90029-000 x x x
13 A Control Panel, Outer Jacket
105-00118-000 x x
105-00119-000 x x x x x
