77
14 A Outer Jacket Left Panel (Top)
136-00106-000 x
136-00109-000 x
136-00111-000 x x
136-00107-000 x x x
15 A Outer Jacket Side Panel (Bottom)
136-00105-000 x
136-00110-000 x
136-00112-000 x x
136-00108-000 x x x
16 A Outer Jacket Right Panel (Top)
136-00106-000 x
136-00109-000 x
136-00111-000 x x
136-00107-000 x x x
17 A Top Cover
019-00088-000 x
019-00091-000 x
019-00090-000 x x x x x
18 A Literature Pocket 125-00458-000 x
19 A Bezel (Bottom)
019-00200-000 x x x x
019-00201-000 x x x
20 A Bezel (Top) 832-18241-000 x
21 A Top Cover Front
125-90027-000 x x
125-90030-000 x x
125-90028-000 x x x
22 A Condensate Box Assembly 125-00520-000 x
23 A Manual reset high limit
817-11064-000 x
858-11560-000
(DHW)
x
24 A Auto reset high limit
817-11063-000 x
836-09717-000
(DHW)
x
25 A Victaulic Coupling
221-00432-000 x
221-00433-000 x
221-00435-000 x x x
221-00436-000 x x
26 A External Pipe Assembly - INLET
109898-13-EXT x
109241-13-EXT x
109956-13-01 x x
109245-15-01 x
109246-15-1 x x
27 A External Pipe Assembly - OUTLET
109898-15-EXT x
109953-15-EXT x
109956-15-01 x x
109245-17-01 x
109246-17-1 x x
28 A Lid Pull 037-00608-000 x
